Used to detect the weight of product whether match with the target weight, Enjoy high accuracy and advanced features with a standard system suitable for food, personal care or pharmaceutical applications. It is suitable for different kind of packaged product, such as cartons, bags, cups, bottles, jars, pouches, boxes, etc.
หมวดหมู่ : เครื่องชั่งอัตโนมัติ ,
แบรนด์ : YAMASHIDA (ยามาชิดะ)
Share
MODEL | YA-02-CW-220-1000G-W |
WEIGHING RANGE (Optional) | 0.1 kg – 1kg |
SPEED (ADJUSTABLE) | 60 - 80 Bag/Min |
WEIGHING ACCURACY | ± 0.5g ~ 1g |
BELT WIDTH | 220 mm |
MIDDLE WEIGHT BELT SIZE (WxL) | 220 x 450 |
MIN.SCALE (FLUCTUATION) | 0.1 g |
PRELIMINARY PROGRAM (SET) | 100 |
DATA OUTPUT | USB |
COMUNICATION PORT | Modbus TCP / Network Port |
NW / GW | 150 kg / 270 kg |
ELIMINATE OPTIONAL DEVICE | Sorting Device (belt width 150 mm) |
AIR REQUIREMENTS (REFERENCE) | 0.3 – 0.6 mpa |
VOLTAGE | 220V, single phase, 50/60Hz |
POWER | 300W |
